EP103 ECHOPLEX® DELAY
DESCRIPTION
• Vintage Echoplex EP-3 tape echo warmth and modulation
• Audiophile quality audio paths
• 100% analog dry path
• Studio-grade low noise floor
• Age control varies delay tone from pristine to dark and dirty
• Delay control provides 65–750ms of delay time
• Tap jack provides up to 4 seconds of delay time with external Tap Tempo Switch
SPECIFICATIONS
Input Impedance, 1 MΩ
Output Impedance, 100 Ω
Max Input, +5 dBV
Max Output Level, +5 dBV
Noise Floor, -107 dBV
Sampling Rate, 96 kHz
Current Draw, 240 mA
Power Supply, 9 volts DC
AGE MODE
The EP103’s Age function simulates the sonic qualities of an aging EP-3. To access:
1. Push and hold VOLUME control for 2 seconds until AGE LED flashes.
2. Rotate VOLUME control counterclockwise for a bright, pristine tape echo sound; rotate control clockwise for a darker and more modulated, aged tape echo sound.
3. Push VOLUME control to lock your Age setting and return to normal operation.
4. AGE LED indicates Age mode is active. Press once on VOLUME control to toggle between your Age setting and the default clear, pristine sound (LED off).
NOTE: You may notice that the EP103’s housing warms up while on. This is completely normal. Take care when operating in extremely high ambient temperatures or direct sunlight.
DESCRIPTION
• Vintage Echoplex EP-3 tape echo warmth and modulation
• Audiophile quality audio paths
• 100% analog dry path
• Studio-grade low noise floor
• Age control varies delay tone from pristine to dark and dirty
• Delay control provides 65–750ms of delay time
• Tap jack provides up to 4 seconds of delay time with external Tap Tempo Switch
SPECIFICATIONS
Input Impedance, 1 MΩ
Output Impedance, 100 Ω
Max Input, +5 dBV
Max Output Level, +5 dBV
Noise Floor, -107 dBV
Sampling Rate, 96 kHz
Current Draw, 240 mA
Power Supply, 9 volts DC
AGE MODE
The EP103’s Age function simulates the sonic qualities of an aging EP-3. To access:
1. Push and hold VOLUME control for 2 seconds until AGE LED flashes.
2. Rotate VOLUME control counterclockwise for a bright, pristine tape echo sound; rotate control clockwise for a darker and more modulated, aged tape echo sound.
3. Push VOLUME control to lock your Age setting and return to normal operation.
4. AGE LED indicates Age mode is active. Press once on VOLUME control to toggle between your Age setting and the default clear, pristine sound (LED off).
NOTE: You may notice that the EP103’s housing warms up while on. This is completely normal. Take care when operating in extremely high ambient temperatures or direct sunlight.
