MXR EG74 RAW DAWG OD

EG74 Raw Dawg Overdrive™

This pedal gives Eric Gales all the seasoning he needs to serve up some of the tastiest licks in the business. It’s a classic crunchy OD circuit customized for a more balanced midrange and a bump in gain, providing a sweet, organic sound—even when it’s time to crank up the heat.

Specifications
Input Impedance > 450 kΩ
Output Impedance < 100 Ω
Noise Floor* < -100 dBV
Gain -  21 to 47 dB
Bypass - True Hardwire
Current Draw - 6 mA
Power Requirements - 9 VDC
Measurements made at 1 kHz
*All controls at mid-position, A-weighted
